Features
• Disconnection facility allows lines to be disconnected temporarily
for testing
• Fully compatible with industry standard back mount frames,insertion
tools, connection boxes, designation strips and other accessories
• UK OFTEL approved
• High specification silver plated contacts maintain electrical
performance after multiple insertions
• Industry standard LSA+ type contacts
• ISO 9001 approved manufacturing
• OEM available for rebranding or re-design
Specifications
Dimensions: 123mm x 20.5mm x 39.5mm
Housing: PBT (Flame retardancy satisfies UL94V-0 and EN60950)
Contacts: Silver plated Phosphor Bronze (Thickness 100μ” /2.54μm)
Electrical Performance
Copper conductor diameter: 0.40 to 0.63mm
Wire connections per slot: 2
Standard working voltage: 50V DC (+5/-0) or 70V AC
Insulation resistance: ≥1GΩ (500V DC ±50V DC)
Dielectic strength: 2.0kV rms
Contact resistance (in connection points): <10mΩ
Contact resistance (with the protection device): ≤30mΩ
Impulse breakdown voltage: 210-230V
Mechanical Data
Wire Insertion Force: 35-70N
Wire Pull-Out Force: 9.0N
Wire Retention Force: 80% of wire breaking force
Environmental Data
Temperature range: Storage -40°C to 90°C
Operational - 20°C to 80°C
Humidity: 5% to 95%
Oftel
This product complies with UK government OFTEL Approval NS/G/1235 W100025 for use in standard telecommunications wiring distribution systems.
**Also available 6089/1/812/00-60891812-00**
